| Part Number | HR5P-N4CA-00000 | HR5P-N4FA-00000 | HR5P-N4CB-00000 | HR5P-N1CA-00000 | HR5P-N2CA-00000 | HR5P-N3CA-00000 |
|---|---|---|---|---|---|---|
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Product Status | Active | Active | Active | Active | Active | Active |
| Type | Infrared (IR) | Infrared (IR) | Infrared (IR) | Infrared (IR) | - | - |
| Current - DC Forward (If) (Max) | 100mA | 100mA | 100mA | 100mA | - | - |
| Radiant Intensity (Ie) Min @ If | 71.5mW/sr @ 100mA | 28.5mW/sr @ 100mA | 71.5mW/sr @ 100mA | 71.5mW/sr @ 100mA | - | - |
| Wavelength | 940nm | 940nm | 940nm | 850nm | - | - |
| Voltage - Forward (Vf) (Typ) | 1.52V | 1.52V | 1.42V | 1.66V | - | - |
| Viewing Angle | 30° | 50° | 30° | 30° | - | - |
| Orientation | Top View | Top View | Top View | Top View | - | - |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | - | - |
| Package / Case | Radial | Radial | Radial | Radial | - | - |
