HCPL-6551
  • Share:

Broadcom Limited HCPL-6551

Manufacturer No:
HCPL-6551
Manufacturer:
Broadcom Limited
Package:
Bulk
Datasheet:
HCPL-6551 Datasheet
ECAD Model:
-
Description:
OPTOISO 1.5KV TRANS W/BASE 16DFF
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Number of Channels:4
Voltage - Isolation:1500VDC
Current Transfer Ratio (Min):9% @ 16mA
Current Transfer Ratio (Max):-
Turn On / Turn Off Time (Typ):400ns, 1µs
Rise / Fall Time (Typ):-
Input Type:DC
Output Type:Transistor with Base
Voltage - Output (Max):20V
Current - Output / Channel:8mA
Voltage - Forward (Vf) (Typ):1.55V
Current - DC Forward (If) (Max):20 mA
Vce Saturation (Max):-
Operating Temperature:-55°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:16-Flatpack
Supplier Device Package:16-Flatpack
0 Remaining View Similar

In Stock

$161.83
7

Please send RFQ , we will respond immediately.
