| Part Number | ATF-52189-BLK | ATF-53189-BLK | ATF-50189-BLK |
|---|---|---|---|
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Product Status | Obsolete | Obsolete | Obsolete |
| Transistor Type | E-pHEMT | E-pHEMT | E-pHEMT |
| Frequency | 2GHz | 900MHz | 2GHz |
| Gain | 16dB | 17.2dB | 15.5dB |
| Voltage - Test | 4.5 V | 4 V | 4.5 V |
| Current Rating (Amps) | 500mA | 300mA | 1A |
| Noise Figure | 1.5dB | 0.8dB | 1.1dB |
| Current - Test | 200 mA | 135 mA | 280 mA |
| Power - Output | 27dBm | 21.7dBm | 29dBm |
| Voltage - Rated | 7 V | 7 V | - |
| Package / Case | TO-243AA | TO-243AA | TO-243AA |
| Supplier Device Package | SOT-89 | SOT-89-3 | SOT-89 |
