| Color: | Red, Green, Blue (RGB) | |
| Wavelength: | 625nm Red, 525nm Green, 460nm Blue | |
| Current - Test: | 350mA Red, 350mA Green, 350mA Blue | |
| Voltage - Forward (Vf) (Typ): | 2.1V Red, 3.2V Green, 3.2V Blue | |
| Lumens/Watt @ Current - Test: | 54 lm/W Red, 76 lm/W Green, 20 lm/W Blue | |
| Current - Max: | 350mA Red, 350mA Green, 350mA Blue | |
| Luminous Flux @ Current/Temperature: | 40lm Red, 85lm Green, 22lm Blue | |
| Temperature - Test: | 25°C | |
| Viewing Angle: | 120° | |
| Mounting Type: | Surface Mount | |
| Package / Case: | TO-252-3, DPak (2 Leads + Tab), SC-63 | |
| Supplier Device Package: | - | |
| Size / Dimension: | 0.335" L x 0.335" W (8.50mm x 8.50mm) | |
| Height - Seated (Max): | 0.134" (3.40mm) | |
