SRU5018-150Y
  • Share:

Bourns Inc. SRU5018-150Y

Manufacturer No:
SRU5018-150Y
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRU5018-150Y Datasheet
ECAD Model:
-
Description:
FIXED IND 15UH 950MA 100MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:15 µH
Tolerance:±30%
Current Rating (Amps):950 mA
Current - Saturation (Isat):800mA
Shielding:Shielded
DC Resistance (DCR):100mOhm
Q @ Freq:12 @ 2.52MHz
Frequency - Self Resonant:40MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.205" L x 0.205" W (5.20mm x 5.20mm)
Height - Seated (Max):0.079" (2.00mm)
0 Remaining View Similar

In Stock

$0.93
876

Please send RFQ , we will respond immediately.

Similar Products

Part Number SRU5018-150Y SRU5018-1R0Y   SRU5028-150Y   SRU5011-150Y   SRU5016-150Y   SRU5018-100Y
Manufacturer Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc.
Product Status Active Active Active Active Active Active
Type Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite
Inductance 15 µH 1 µH 15 µH 15 µH 15 µH 10 µH
Tolerance ±30% ±30% ±30% ±30% ±30% ±30%
Current Rating (Amps) 950 mA 2.8 A 1.1 A 600 mA 800 mA 1.25 A
Current - Saturation (Isat) 800mA 2.85A 1A 480mA 720mA 1.05A
Shielding Shielded Shielded Shielded Shielded Shielded Shielded
DC Resistance (DCR) 100mOhm 12.5mOhm 108mOhm 250mOhm 130mOhm 65mOhm
Q @ Freq 12 @ 2.52MHz 9 @ 7.96MHz 18 @ 2.52MHz 12 @ 2.52MHz 15 @ 2.52MHz 12 @ 2.52MHz
Frequency - Self Resonant 40MHz 200MHz 23MHz 42MHz 32MHz 50MHz
Ratings - - - - - -
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Inductance Frequency - Test 100 kHz 100 kHz 100 kHz 100 kHz 100 kHz 100 kHz
Features - - - - - -
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard Nonstandard Nonstandard Nonstandard Nonstandard
Supplier Device Package - - - - - -
Size / Dimension 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm)
Height - Seated (Max) 0.079" (2.00mm) 0.079" (2.00mm) 0.118" (3.00mm) 0.047" (1.20mm) 0.071" (1.80mm) 0.079" (2.00mm)
