SRU5011-100Y
  • Share:

Bourns Inc. SRU5011-100Y

Manufacturer No:
SRU5011-100Y
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRU5011-100Y Datasheet
ECAD Model:
-
Description:
FIXED IND 10UH 700MA 170MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:10 µH
Tolerance:±30%
Current Rating (Amps):700 mA
Current - Saturation (Isat):580mA
Shielding:Shielded
DC Resistance (DCR):170mOhm
Q @ Freq:12 @ 7.96MHz
Frequency - Self Resonant:50MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.205" L x 0.205" W (5.20mm x 5.20mm)
Height - Seated (Max):0.047" (1.20mm)
0 Remaining View Similar

In Stock

$0.38
235

Please send RFQ , we will respond immediately.

Similar Products

Part Number SRU5011-100Y SRU5016-100Y   SRU5018-100Y   SRU5011-101Y   SRU5011-150Y   SRU2011-100Y   SRU3011-100Y
Manufacturer Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc.
Product Status Active Active Active Active Active Active Active
Type Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite
Inductance 10 µH 10 µH 10 µH 100 µH 15 µH 10 µH 10 µH
Tolerance ±30% ±30% ±30% ±30% ±30% ±30% ±30%
Current Rating (Amps) 700 mA 1 A 1.25 A 200 mA 600 mA 520 mA 400 mA
Current - Saturation (Isat) 580mA 900mA 1.05A 180mA 480mA 400mA 350mA
Shielding Shielded Shielded Shielded Shielded Shielded Shielded Shielded
DC Resistance (DCR) 170mOhm 84mOhm 65mOhm 1.6Ohm 250mOhm 740mOhm Max 340mOhm
Q @ Freq 12 @ 7.96MHz 15 @ 2.52MHz 12 @ 2.52MHz 30 @ 796kHz 12 @ 2.52MHz 10 @ 2.52MHz 8 @ 2.52MHz
Frequency - Self Resonant 50MHz 40MHz 50MHz 15MHz 42MHz 45MHz 60MHz
Ratings - - - - - - -
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Inductance Frequency - Test 100 kHz 100 kHz 100 kHz 100 kHz 100 kHz 100 kHz 100 kHz
Features - - - - - - -
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard Nonstandard Nonstandard Nonstandard Nonstandard Nonstandard
Supplier Device Package - - - - - - -
Size / Dimension 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.205" L x 0.205" W (5.20mm x 5.20mm) 0.110" L x 0.110" W (2.80mm x 2.80mm) 0.138" L x 0.130" W (3.50mm x 3.30mm)
Height - Seated (Max) 0.047" (1.20mm) 0.071" (1.80mm) 0.079" (2.00mm) 0.047" (1.20mm) 0.047" (1.20mm) 0.047" (1.20mm) 0.047" (1.20mm)
