| Part Number | SRR1240-3R9M | SRR1240-3R9Y |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 3.9 µH | 3.9 µH |
| Tolerance | ±20% | ±30% |
| Current Rating (Amps) | 6.35 A | 6.35 A |
| Current - Saturation (Isat) | 6.2A | 6.2A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 15mOhm Max | 15mOhm Max |
| Q @ Freq | 14 @ 7.96MHz | 14 @ 7.96MHz |
| Frequency - Self Resonant | 39MHz | 39MHz |
| Ratings | - | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Height - Seated (Max) | 0.177" (4.50mm) | 0.177" (4.50mm) |
