| Part Number | SRP6540-220M | SRP6540-270M |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Iron Powder | Iron Powder |
| Inductance | 22 µH | 27 µH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 2.5 A | 2 A |
| Current - Saturation (Isat) | 2.5A | 2A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 133mOhm Max | 290mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.283" L x 0.256" W (7.20mm x 6.50mm) | 0.283" L x 0.256" W (7.20mm x 6.50mm) |
| Height - Seated (Max) | 0.157" (4.00mm) | 0.157" (4.00mm) |
