SRP5050FA-6R8M
  • Share:

Bourns Inc. SRP5050FA-6R8M

Manufacturer No:
SRP5050FA-6R8M
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRP5050FA-6R8M Datasheet
ECAD Model:
-
Description:
FIXED IND 6.8UH 6.4A 28.6MOHM SM
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Metal
Inductance:6.8 µH
Tolerance:±20%
Current Rating (Amps):6.4 A
Current - Saturation (Isat):7.8A
Shielding:Shielded
DC Resistance (DCR):28.6mOhm Max
Q @ Freq:-
Frequency - Self Resonant:18MHz
Ratings:AEC-Q200
Operating Temperature:-55°C ~ 155°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.217" L x 0.209" W (5.50mm x 5.30mm)
Height - Seated (Max):0.197" (5.00mm)
0 Remaining View Similar

In Stock

$1.76
511

Please send RFQ , we will respond immediately.
