Please send RFQ , we will respond immediately.
| Part Number | SRP5030TA-6R8M | SRP5020TA-6R8M | SRP5030T-6R8M |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Carbonyl Powder | Metal | Iron Powder |
| Inductance | 6.8 µH | 6.8 µH | 6.8 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 4 A | 2.4 A | 4 A |
| Current - Saturation (Isat) | 4.3A | 3.8A | 4.3A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 76.2mOhm Max | 150mOhm Max | 76.2mOhm Max |
| Q @ Freq | 15 @ 100kHz | 20 @ 100kHz | - |
| Frequency - Self Resonant | 19MHz | 23MHz | - |
| Ratings | AEC-Q200 | AEC-Q200 | - |
| Operating Temperature | -40°C ~ 150°C | -40°C ~ 105°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.224" L x 0.205" W (5.70mm x 5.20mm) |
| Height - Seated (Max) | 0.118" (3.00mm) | 0.079" (2.00mm) | 0.118" (3.00mm) |
