Please send RFQ , we will respond immediately.
| Part Number | SRP5030C-R47M | SRP5030T-R47M | SRP5020C-R47M |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Type | - | Drum Core, Wirewound | - |
| Material - Core | Metal | Iron Powder | Metal |
| Inductance | 470 nH | 470 nH | 470 nH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 16 A | 12 A | 11.5 A |
| Current - Saturation (Isat) | 17A | 16A | 16A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 7.4mOhm Max | 7.4mOhm Max | 7.6mOhm Max |
| Q @ Freq | 20 @ 100kHz | - | 10 @ 100kHz |
| Frequency - Self Resonant | 60MHz | - | 80MHz |
| Ratings | - | - | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.224" L x 0.205" W (5.70mm x 5.20mm) |
| Height - Seated (Max) | 0.118" (3.00mm) | 0.118" (3.00mm) | 0.079" (2.00mm) |
