| Part Number | SRP4020-1R5M | SRP4020-1R0M | SRP4020-1R2M |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Type | Molded | Molded | Molded |
| Material - Core | Iron | Iron | Iron |
| Inductance | 1.5 µH | 1 µH | 1.2 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 5.1 A | 5 A | 5 A |
| Current - Saturation (Isat) | 5A | 6A | 5A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 29mOhm Max | 21.6mOhm Max | 22mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | - | - | - |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.189" L x 0.157" W (4.80mm x 4.00mm) | 0.189" L x 0.157" W (4.80mm x 4.00mm) | 0.189" L x 0.157" W (4.80mm x 4.00mm) |
| Height - Seated (Max) | 0.079" (2.00mm) | 0.079" (2.00mm) | 0.079" (2.00mm) |
