SRP1205-1R8Y
  • Share:

Bourns Inc. SRP1205-1R8Y

Manufacturer No:
SRP1205-1R8Y
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRP1205-1R8Y Datasheet
ECAD Model:
-
Description:
FIXED IND 1.8UH 13A 3.4 MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:1.8 µH
Tolerance:±25%
Current Rating (Amps):13 A
Current - Saturation (Isat):16A
Shielding:Shielded
DC Resistance (DCR):3.4mOhm Max
Q @ Freq:-
Frequency - Self Resonant:55MHz
Ratings:-
Operating Temperature:-55°C ~ 150°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max):0.220" (5.60mm)
0 Remaining View Similar

In Stock

-
188

Please send RFQ , we will respond immediately.

Similar Products

Part Number SRP1205-1R8Y SRP1205-1R0Y
Manufacturer Bourns Inc. Bourns Inc.
Product Status Obsolete Obsolete
Type Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite
Inductance 1.8 µH 1 µH
Tolerance ±25% ±25%
Current Rating (Amps) 13 A 14 A
Current - Saturation (Isat) 16A 22A
Shielding Shielded Shielded
DC Resistance (DCR) 3.4mOhm Max 3.4mOhm Max
Q @ Freq - -
Frequency - Self Resonant 55MHz 75MHz
Ratings - -
Operating Temperature -55°C ~ 150°C -55°C ~ 150°C
Inductance Frequency - Test 100 kHz 100 kHz
Features - -
Mounting Type Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard
Supplier Device Package - -
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm) 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max) 0.220" (5.60mm) 0.197" (5.00mm)
