SRP0520-6R8K
  • Share:

Bourns Inc. SRP0520-6R8K

Manufacturer No:
SRP0520-6R8K
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRP0520-6R8K Datasheet
ECAD Model:
-
Description:
FIXED IND 6.8UH 3.5A 80 MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:-
Material - Core:Metal
Inductance:6.8 µH
Tolerance:±10%
Current Rating (Amps):3.5 A
Current - Saturation (Isat):4.8A
Shielding:Shielded
DC Resistance (DCR):80mOhm Max
Q @ Freq:15 @ 7.96MHz
Frequency - Self Resonant:14MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.213" L x 0.201" W (5.40mm x 5.10mm)
Height - Seated (Max):0.079" (2.00mm)
0 Remaining View Similar

In Stock

$1.15
97

Please send RFQ , we will respond immediately.

Similar Products

Part Number SRP0520-6R8K SRP0620-6R8K   SRP0420-6R8K   SRP0510-6R8K
Manufacturer Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc.
Product Status Active Active Active Last Time Buy
Type - - - -
Material - Core Metal Metal Metal Metal
Inductance 6.8 µH 6.8 µH 6.8 µH 6.8 µH
Tolerance ±10% ±10% ±10% ±10%
Current Rating (Amps) 3.5 A 4.5 A 2.6 A 2.2 A
Current - Saturation (Isat) 4.8A 6A 3.8A 3A
Shielding Shielded Shielded Shielded Shielded
DC Resistance (DCR) 80mOhm Max 63mOhm Max 117mOhm Max 198mOhm Max
Q @ Freq 15 @ 7.96MHz 26 @ 7.96MHz 27 @ 7.96MHz 18 @ 7.96MHz
Frequency - Self Resonant 14MHz 12MHz 20MHz 16MHz
Ratings - - - -
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Inductance Frequency - Test 100 kHz 100 kHz 100 kHz 100 kHz
Features - - - -
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard Nonstandard Nonstandard
Supplier Device Package - - - -
Size / Dimension 0.213" L x 0.201" W (5.40mm x 5.10mm) 0.280" L x 0.264" W (7.10mm x 6.70mm) 0.173" L x 0.161" W (4.40mm x 4.10mm) 0.213" L x 0.201" W (5.40mm x 5.10mm)
Height - Seated (Max) 0.079" (2.00mm) 0.079" (2.00mm) 0.079" (2.00mm) 0.039" (1.00mm)
