SRN3015C-6R8M
  • Share:

Bourns Inc. SRN3015C-6R8M

Manufacturer No:
SRN3015C-6R8M
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SRN3015C-6R8M Datasheet
ECAD Model:
-
Description:
IND,3X3X1.3MM,6.8UH20%,1.7A,SHD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:-
Material - Core:Ferrite
Inductance:6.8 µH
Tolerance:±20%
Current Rating (Amps):1.7 A
Current - Saturation (Isat):1.3A
Shielding:Semi-Shielded
DC Resistance (DCR):206mOhm Max
Q @ Freq:10 @ 100MHz
Frequency - Self Resonant:36MHz
Ratings:-
Operating Temperature:-55°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:3015
Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max):0.059" (1.50mm)
0 Remaining View Similar

In Stock

$0.48
1,646

Please send RFQ , we will respond immediately.

Similar Products

Part Number SRN3015C-6R8M SRN3015-6R8M
Manufacturer Bourns Inc. Bourns Inc.
Product Status Active Active
Type - Drum Core, Wirewound
Material - Core Ferrite Ferrite
Inductance 6.8 µH 6.8 µH
Tolerance ±20% ±20%
Current Rating (Amps) 1.7 A 1.1 A
Current - Saturation (Isat) 1.3A 1.05A
Shielding Semi-Shielded Semi-Shielded
DC Resistance (DCR) 206mOhm Max 211mOhm Max
Q @ Freq 10 @ 100MHz 10 @ 7.96MHz
Frequency - Self Resonant 36MHz 50MHz
Ratings - -
Operating Temperature -55°C ~ 125°C -40°C ~ 125°C
Inductance Frequency - Test 100 kHz 1 MHz
Features - -
Mounting Type Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard
Supplier Device Package 3015 -
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm) 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) 0.059" (1.50mm) 0.059" (1.50mm)
