Bourns Inc.-SRF0703-4R7M - Arrays, Signal Transformers Product Specifications and Latest Quotes

Number of Coils:	2
Inductance - Connected In Parallel:	4.7 µH
Inductance - Connected In Series:	18.8 µH
Tolerance:	±20%
Current Rating - Parallel:	3.09 A
Current Rating - Series:	1.55 A
Current Saturation - Parallel:	3.78 A
Current Saturation - Series:	1.89 A
DC Resistance (DCR) - Parallel:	40.6mOhm Max
DC Resistance (DCR) - Series:	242mOhm Max
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.299" L x 0.299" W (7.60mm x 7.60mm)
Height:	0.142" (3.60mm)

Bourns Inc. SRF0703-4R7M
