| Part Number | SDR0906-152KB | SDR0906-152KL |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 1.5 mH | 1.5 mH |
| Tolerance | ±10% | ±10% |
| Current Rating (Amps) | 180 mA | 180 mA |
| Current - Saturation (Isat) | 260mA | 260mA |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 5Ohm Max | 5Ohm Max |
| Q @ Freq | 70 @ 252kHz | 70 @ 252kHz |
| Frequency - Self Resonant | 2MHz | 2MHz |
| Ratings | - | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 kHz | 1 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.492" L x 0.413" W (12.50mm x 10.50mm) | 0.492" L x 0.413" W (12.50mm x 10.50mm) |
| Height - Seated (Max) | 0.248" (6.30mm) | 0.248" (6.30mm) |
