SDE6603-1R5M
  • Share:

Bourns Inc. SDE6603-1R5M

Manufacturer No:
SDE6603-1R5M
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
SDE6603-1R5M Datasheet
ECAD Model:
-
Description:
FIXED IND 1.5UH 2.8A 60 MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:1.5 µH
Tolerance:±20%
Current Rating (Amps):2.8 A
Current - Saturation (Isat):2.6A
Shielding:Unshielded
DC Resistance (DCR):60mOhm Max
Q @ Freq:-
Frequency - Self Resonant:115MHz
Ratings:-
Operating Temperature:-25°C ~ 105°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max):0.115" (2.92mm)
0 Remaining View Similar

In Stock

-
202

Please send RFQ , we will respond immediately.

Similar Products

Part Number SDE6603-1R5M SDE6603-1R0M
Manufacturer Bourns Inc. Bourns Inc.
Product Status Obsolete Obsolete
Type Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite
Inductance 1.5 µH 1 µH
Tolerance ±20% ±20%
Current Rating (Amps) 2.8 A 2.9 A
Current - Saturation (Isat) 2.6A 2.9A
Shielding Unshielded Unshielded
DC Resistance (DCR) 60mOhm Max 50mOhm Max
Q @ Freq - -
Frequency - Self Resonant 115MHz 130MHz
Ratings - -
Operating Temperature -25°C ~ 105°C -25°C ~ 105°C
Inductance Frequency - Test 100 kHz 100 kHz
Features - -
Mounting Type Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard
Supplier Device Package - -
Size / Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm) 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm) 0.115" (2.92mm)
