| Part Number | SDE0604A-4R7M | SDE0604A-2R7M |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 4.7 µH | 2.7 µH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 3.4 A | 4 A |
| Current - Saturation (Isat) | 3A | 3.8A |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 70mOhm Max | 55mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | 47MHz | 60MHz |
| Ratings | AEC-Q200 | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz | 1 MHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.228" L x 0.205" W (5.80mm x 5.20mm) |
| Height - Seated (Max) | 0.189" (4.80mm) | 0.189" (4.80mm) |
