| Part Number | PTVS6-076C-M | PTVS3-076C-M | PTVS6-066C-M |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - |
| Bidirectional Channels | 1 | 1 | 1 |
| Voltage - Reverse Standoff (Typ) | 76V | 76V | 66V |
| Voltage - Breakdown (Min) | 85V | 85V | 72V |
| Voltage - Clamping (Max) @ Ipp | 135V | 135V | 120V |
| Current - Peak Pulse (10/1000µs) | 6000A (6kA) (8/20µs) | 3000A (3kA) (8/20µs) | 6000A (6kA) (8/20µs) |
| Power - Peak Pulse | - | - | - |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | 3300pF @ 10kHz | 1700pF @ 10kHz | 4100pF @ 10kHz |
| Operating Temperature | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 2-SMD, Flat Lead | 2-SMD, Flat Lead | 2-SMD, Flat Lead |
| Supplier Device Package | - | - | - |
