PQ2617BHA-330K
  • Share:

Bourns Inc. PQ2617BHA-330K

Manufacturer No:
PQ2617BHA-330K
Manufacturer:
Bourns Inc.
Package:
Tray
Datasheet:
PQ2617BHA-330K Datasheet
ECAD Model:
-
Description:
FIXED IND 33UH 28A 2.5 MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:33 µH
Tolerance:±10%
Current Rating (Amps):28 A
Current - Saturation (Isat):8.7A
Shielding:Shielded
DC Resistance (DCR):2.5mOhm Max
Q @ Freq:-
Frequency - Self Resonant:10MHz
Ratings:AEC-Q200
Operating Temperature:-40°C ~ 155°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:1.098" L x 0.780" W (27.90mm x 19.80mm)
Height - Seated (Max):0.748" (19.00mm)
0 Remaining View Similar

In Stock

$4.43
208

Please send RFQ , we will respond immediately.

Similar Products

Part Number PQ2617BHA-330K PQ2614BHA-330K
Manufacturer Bourns Inc. Bourns Inc.
Product Status Active Active
Type Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite
Inductance 33 µH 33 µH
Tolerance ±10% ±10%
Current Rating (Amps) 28 A 30 A
Current - Saturation (Isat) 8.7A 5.1A
Shielding Shielded Shielded
DC Resistance (DCR) 2.5mOhm Max 1.9mOhm Max
Q @ Freq - -
Frequency - Self Resonant 10MHz 8MHz
Ratings AEC-Q200 AEC-Q200
Operating Temperature -40°C ~ 155°C -40°C ~ 155°C
Inductance Frequency - Test 100 kHz 100 kHz
Features - -
Mounting Type Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard
Supplier Device Package - -
Size / Dimension 1.098" L x 0.780" W (27.90mm x 19.80mm) 1.098" L x 0.780" W (27.90mm x 19.80mm)
Height - Seated (Max) 0.748" (19.00mm) 0.630" (16.00mm)
