PM74SB-470L-RC
  • Share:

Bourns Inc. PM74SB-470L-RC

Manufacturer No:
PM74SB-470L-RC
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
PM74SB-470L-RC Datasheet
ECAD Model:
-
Description:
FIXED IND 47UH 800MA 270MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:47 µH
Tolerance:±15%
Current Rating (Amps):800 mA
Current - Saturation (Isat):950mA
Shielding:Shielded
DC Resistance (DCR):270mOhm Max
Q @ Freq:-
Frequency - Self Resonant:12MHz
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max):0.193" (4.90mm)
0 Remaining View Similar

In Stock

$0.77
908

Please send RFQ , we will respond immediately.
