PM1038S-1R7M-RC
  • Share:

Bourns Inc. PM1038S-1R7M-RC

Manufacturer No:
PM1038S-1R7M-RC
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
PM1038S-1R7M-RC Datasheet
ECAD Model:
-
Description:
FIXED IND 1.7UH 15A 7.5 MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:-
Material - Core:Iron
Inductance:1.7 µH
Tolerance:±20%
Current Rating (Amps):15 A
Current - Saturation (Isat):18A
Shielding:Shielded
DC Resistance (DCR):7.5mOhm Max
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-55°C ~ 150°C
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.465" L x 0.413" W (11.80mm x 10.50mm)
Height - Seated (Max):0.165" (4.20mm)
0 Remaining View Similar

In Stock

-
596

Please send RFQ , we will respond immediately.

Similar Products

Part Number PM1038S-1R7M-RC PM1038S-1R2M-RC
Manufacturer Bourns Inc. Bourns Inc.
Product Status Obsolete Obsolete
Type - -
Material - Core Iron Iron
Inductance 1.7 µH 1.2 µH
Tolerance ±20% ±20%
Current Rating (Amps) 15 A 18 A
Current - Saturation (Isat) 18A 24A
Shielding Shielded Shielded
DC Resistance (DCR) 7.5mOhm Max 4.7mOhm Max
Q @ Freq - -
Frequency - Self Resonant - -
Ratings - -
Operating Temperature -55°C ~ 150°C -55°C ~ 150°C
Inductance Frequency - Test 100 kHz 100 kHz
Features - -
Mounting Type Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard
Supplier Device Package - -
Size / Dimension 0.465" L x 0.413" W (11.80mm x 10.50mm) 0.465" L x 0.413" W (11.80mm x 10.50mm)
Height - Seated (Max) 0.165" (4.20mm) 0.165" (4.20mm)
