PDB181-K420K-103B
  • Share:

Bourns Inc. PDB181-K420K-103B

Manufacturer No:
PDB181-K420K-103B
Manufacturer:
Bourns Inc.
Package:
Bulk
Datasheet:
PDB181-K420K-103B Datasheet
ECAD Model:
-
Description:
POT 10K OHM 1/5W CARBON LINEAR
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Resistance (Ohms):10k
Tolerance:±20%
Power (Watts):0.2W, 1/5W
Built in Switch:None
Number of Turns:1
Features:-
Taper:Linear
Number of Gangs:1
Adjustment Type:Side Adjustment
Temperature Coefficient:-
Rotation:300°
Resistive Material:Carbon
Termination Style:PC Pins
Actuator Type:Knurled and Slotted
Actuator Length:0.787" (20.00mm)
Actuator Diameter:0.236" (6.00mm)
Bushing Thread:M7 x 0.75
Mounting Type:Panel Mount
0 Remaining View Similar

In Stock

$1.46
78

Please send RFQ , we will respond immediately.

Similar Products

Part Number PDB181-K420K-103B PDB181-K420K-104B   PDB181-K420K-203B   PDB181-K420K-105B   PDB182-K420K-103B   PDB181-A420K-103B   PDB181-E420K-103B   PDB181-K220K-103B   PDB181-K420F-103B   PDB181-K420K-102B
Manufacturer Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc. Bourns Inc.
Product Status Active Active Active Active Active Active Active Active Active Active
Resistance (Ohms) 10k 100k 20k 1M 10k 10k 10k 10k 10k 1K
Tolerance ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20%
Power (Watts) 0.2W, 1/5W 0.2W, 1/5W 0.2W, 1/5W 0.2W, 1/5W 0.125W, 1/8W 0.2W, 1/5W 0.2W, 1/5W 0.2W, 1/5W 0.2W, 1/5W 0.2W, 1/5W
Built in Switch None None None None None None None Detent None None
Number of Turns 1 1 1 1 1 1 1 1 1 1
Features - - - - - - - - - -
Taper Linear Linear Linear Linear Linear Linear Linear Linear Linear Linear
Number of Gangs 1 1 1 1 2 1 1 1 1 1
Adjustment Type Side Adjustment Side Adjustment Side Adjustment Side Adjustment Side Adjustment Side Adjustment User Defined Side Adjustment Side Adjustment Side Adjustment
Temperature Coefficient - - - - - - - - - -
Rotation 300° 300° 300° 300° 300° 300° 300° 300° 300° 300°
Resistive Material Carbon Carbon Carbon Carbon Carbon Carbon Carbon Carbon Carbon Carbon
Termination Style PC Pins PC Pins PC Pins PC Pins PC Pins PC Pins Solder Lug PC Pins PC Pins PC Pins
Actuator Type Knurled and Slotted Knurled and Slotted Knurled and Slotted Knurled and Slotted Knurled and Slotted Knurled and Slotted Knurled and Slotted Knurled and Slotted Flatted Knurled and Slotted
Actuator Length 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm) 0.787" (20.00mm)
Actuator Diameter 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm) 0.236" (6.00mm)
Bushing Thread M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75 M7 x 0.75
Mounting Type Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount Panel Mount
