PCS020-EE05500S
  • Share:

Bourns Inc. PCS020-EE05500S

Manufacturer No:
PCS020-EE05500S
Manufacturer:
Bourns Inc.
Package:
Tape & Reel (TR)
Datasheet:
PCS020-EE05500S Datasheet
ECAD Model:
-
Description:
CURRENT SENSE TRANSF 20A 500UH
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Frequency Range:1MHz
Type:Invasive
Current Rating (Amps):20 A
Inductance:500 mH
ET (Volt-Time):27VµS
Turns Ratio - Primary:Secondary:1:50
Current Ratio:50:1
DC Resistance (DCR):7mOhm Primary, 1.5Ohm Secondary Max
Ratings:-
Mounting Type:Surface Mount
Size / Dimension:0.245" L x 0.235" W (6.22mm x 5.97mm)
Height - Seated (Max):0.209" (5.31mm)
Termination Style:Gull Wing
0 Remaining View Similar

In Stock

$2.57
124

Please send RFQ , we will respond immediately.
