| Part Number | MG1608-252Y | MG1608-152Y | MG1608-202Y | MG1608-222Y |
|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Obsolete | Obsolete |
| Filter Type | Differential Mode - Single | Power, Signal Line | Power, Signal Line | Power, Signal Line |
| Number of Lines | 1 | 1 | 1 | 1 |
| Impedance @ Frequency | 2.5 kOhms @ 100 MHz | 1.5 kOhms @ 100 MHz | 2 kOhms @ 100 MHz | 2.2 kOhms @ 100 MHz |
| Current Rating (Max) | - | 50mA | 50mA | 200mA |
| DC Resistance (DCR) (Max) | - | 700mOhm | 800mOhm | 1.5Ohm |
| Ratings | - | - | - | - |
| Operating Temperature | - | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package / Case | 0603 (1608 Metric) | 0603 (1608 Metric) | 0603 (1608 Metric) | 0603 (1608 Metric) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Height (Max) | 0.039" (1.00mm) | 0.039" (1.00mm) | 0.039" (1.00mm) | 0.039" (1.00mm) |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) |
| Features | - | - | - | - |
