| Part Number | CRM2512AFX-10R0ELF | CRM2512AFX-15R0ELF | CRM2512AFX-1000ELF |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Resistance | 10 Ohms | 15 Ohms | 100 Ohms |
| Tolerance | ±1% | ±1% | ±1% |
| Power (Watts) | 2W | 2W | 2W |
| Composition | Thick Film | Thick Film | Thick Film |
| Features | Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding | Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding | Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding |
| Temperature Coefficient | ±100ppm/°C | ±100ppm/°C | ±100ppm/°C |
| Operating Temperature | -55°C ~ 155°C | -55°C ~ 155°C | -55°C ~ 155°C |
| Package / Case | 2512 (6432 Metric) | 2512 (6432 Metric) | 2512 (6432 Metric) |
| Supplier Device Package | 2512 | 2512 | 2512 |
| Ratings | AEC-Q200 | AEC-Q200 | AEC-Q200 |
| Size / Dimension | 0.248" L x 0.122" W (6.30mm x 3.10mm) | 0.252" L x 0.122" W (6.40mm x 3.10mm) | 0.248" L x 0.122" W (6.30mm x 3.10mm) |
| Height - Seated (Max) | 0.031" (0.80mm) | 0.030" (0.75mm) | 0.031" (0.80mm) |
| Number of Terminations | 2 | 2 | 2 |
| Failure Rate | - | - | - |
