| Part Number | 9310-12 | 9310-14 | 9310-32 | 9310-02 |
|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite | Ferrite | Ferrite |
| Inductance | 1 µH | 1.2 µH | 6.8 µH | 220 nH |
| Tolerance | ±10% | ±10% | ±10% | ±20% |
| Current Rating (Amps) | 830 mA | 650 mA | 600 mA | 1.9 A |
| Current - Saturation (Isat) | - | - | - | - |
| Shielding | Unshielded | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 290mOhm Max | 420mOhm Max | 500mOhm Max | 55mOhm Max |
| Q @ Freq | 50 @ 25MHz | 33 @ 7.9MHz | 50 @ 7.9MHz | 50 @ 25MHz |
| Frequency - Self Resonant | 200MHz | 180MHz | 55MHz | 450MHz |
| Ratings | - | - | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 25 MHz | 7.9 MHz | 7.9 MHz | 25 MHz |
| Features | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Supplier Device Package | - | - | - | - |
| Size / Dimension | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) |
| Height - Seated (Max) | - | - | - | - |
