| Part Number | 9310-06 | 9310-36 | 9310-02 |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite | Ferrite |
| Inductance | 470 nH | 10 µH | 220 nH |
| Tolerance | ±20% | ±10% | ±20% |
| Current Rating (Amps) | 1.225 A | 445 mA | 1.9 A |
| Current - Saturation (Isat) | - | - | - |
| Shielding | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 120mOhm Max | 900mOhm Max | 55mOhm Max |
| Q @ Freq | 45 @ 25MHz | 55 @ 7.9MHz | 50 @ 25MHz |
| Frequency - Self Resonant | 310MHz | 45MHz | 450MHz |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 25 MHz | 7.9 MHz | 25 MHz |
| Features | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) |
| Height - Seated (Max) | - | - | - |
