| Part Number | 9250A-103-TR-RC | 9250A-105-TR-RC |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Molded | Molded |
| Material - Core | Ferrite | Ferrite |
| Inductance | 10 µH | 1 mH |
| Tolerance | ±10% | ±10% |
| Current Rating (Amps) | 220 mA | 70 mA |
| Current - Saturation (Isat) | 220mA | 40mA |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 1.62Ohm Max | 17.5Ohm Max |
| Q @ Freq | 50 @ 7.9MHz | 60 @ 790kHz |
| Frequency - Self Resonant | 46MHz | 3.8MHz |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 7.9 MHz | 790 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Axial |
| Supplier Device Package | - | - |
| Size / Dimension | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) |
| Height - Seated (Max) | - | - |
