| Part Number | 9220-28-RC | 9230-28-RC |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Molded |
| Material - Core | Ferrite | Ferrite |
| Inductance | 1 mH | 2.2 µH |
| Tolerance | ±5% | ±10% |
| Current Rating (Amps) | 78 mA | 550 mA |
| Current - Saturation (Isat) | - | - |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 16.5Ohm Max | 400mOhm Max |
| Q @ Freq | 60 @ 7.9MHz | 30 @ 7.9MHz |
| Frequency - Self Resonant | 2.8MHz | 115MHz |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 7.9 MHz | 7.9 MHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Axial |
| Supplier Device Package | - | - |
| Size / Dimension | 0.190" Dia x 0.440" L (4.83mm x 11.18mm) | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) |
| Height - Seated (Max) | - | - |
