| Part Number | 8250-100K-RC | 8250-103K-RC | 8250-102K-RC | 8250-104K-RC |
|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite | Ferrite | Ferrite |
| Inductance | 10 µH | 10 mH | 1 mH | 100 mH |
| Tolerance | ±10% | ±10% | ±10% | ±10% |
| Current Rating (Amps) | 532 mA | 50 mA | 139 mA | 22 mA |
| Current - Saturation (Isat) | 532mA | 14mA | 40mA | 3mA |
| Shielding | Shielded | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 1.27Ohm Max | 93.1Ohm Max | 12.1Ohm Max | 484Ohm Max |
| Q @ Freq | 46 @ 7.9MHz | 70 @ 250kHz | 65 @ 790kHz | 50 @ 79kHz |
| Frequency - Self Resonant | 53MHz | 1.3MHz | 4.5MHz | 320kHz |
| Ratings | - | - | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 7.9 MHz | 250 kHz | 790 kHz | 79 kHz |
| Features | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Supplier Device Package | - | - | - | - |
| Size / Dimension | 0.164" Dia x 0.450" L (4.17mm x 11.43mm) | 0.164" Dia x 0.450" L (4.17mm x 11.43mm) | 0.164" Dia x 0.450" L (4.17mm x 11.43mm) | 0.164" Dia x 0.450" L (4.17mm x 11.43mm) |
| Height - Seated (Max) | - | - | - | - |
