| Part Number | 6310-RC | 6710-RC |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Obsolete |
| Type | Drum Core, Wirewound | Toroidal |
| Material - Core | Ferrite | Iron Powder |
| Inductance | 50 mH | 1 mH |
| Tolerance | ±5% | ±15% |
| Current Rating (Amps) | 65 mA | 1.5 A |
| Current - Saturation (Isat) | - | - |
| Shielding | Unshielded | Shielded |
| DC Resistance (DCR) | 127Ohm Max | 980mOhm Max |
| Q @ Freq | 100 @ 79.6kHz | - |
| Frequency - Self Resonant | 330kHz | - |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 79.6 kHz | 1 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Radial, Vertical, 4 Leads (Open) |
| Supplier Device Package | - | - |
| Size / Dimension | 0.630" Dia x 0.875" L (16.00mm x 22.22mm) | 1.125" L x 0.600" W (28.58mm x 15.24mm) |
| Height - Seated (Max) | - | 1.250" (31.75mm) |
