| Part Number | 5300-22-RC | 5300-25-RC |
|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 56 µH | 100 µH |
| Tolerance | ±10% | ±10% |
| Current Rating (Amps) | 650 mA | 550 mA |
| Current - Saturation (Isat) | 400mA | 300mA |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 470mOhm Max | 670mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | 5.8MHz | 3.9MHz |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 1 kHz | 1 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Axial |
| Supplier Device Package | - | - |
| Size / Dimension | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) |
| Height - Seated (Max) | - | - |
