| Part Number | 4666-RC | 4606-RC | 4626-RC |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Active | Obsolete |
| Type | Drum Core, Wirewound | Wirewound | Drum Core, Wirewound |
| Material - Core | Iron | Phenolic | Iron |
| Inductance | 2.4 mH | 2.4 µH | 24 µH |
| Tolerance | ±5% | ±10% | ±5% |
| Current Rating (Amps) | 160 mA | 1.5 A | 800 mA |
| Current - Saturation (Isat) | - | - | - |
| Shielding | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 15Ohm Max | 190mOhm Max | 340mOhm Max |
| Q @ Freq | 80 @ 252kHz | 56 @ 7.96MHz | 65 @ 2.52MHz |
| Frequency - Self Resonant | 1.7MHz | 120MHz | 25MHz |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 125°C | -55°C ~ 105°C |
| Inductance Frequency - Test | 1 kHz | 7.96 MHz | 2.52 MHz |
| Features | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.530" Dia x 0.875" L (13.46mm x 22.22mm) | 0.270" Dia x 0.750" L (6.86mm x 19.05mm) | 0.290" Dia x 0.875" L (7.37mm x 22.22mm) |
| Height - Seated (Max) | - | - | - |
