| Part Number | 4614X-102-333LF | 4614X-102-330LF | 4614X-102-331LF |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Circuit Type | Isolated | Isolated | Isolated |
| Resistance (Ohms) | 33k | 33 | 330 |
| Tolerance | ±2% | ±1Ohm | ±2% |
| Number of Resistors | 7 | 7 | 7 |
| Resistor Matching Ratio | - | - | - |
| Resistor-Ratio-Drift | - | - | - |
| Number of Pins | 14 | 14 | 14 |
| Power Per Element | 300mW | 300mW | 300mW |
| Temperature Coefficient | ±100ppm/°C | ±250ppm/°C | ±100ppm/°C |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Applications | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | 14-SIP | 14-SIP | 14-SIP |
| Supplier Device Package | 14-SIP | 14-SIP | 14-SIP |
| Size / Dimension | 1.398" L x 0.098" W (35.51mm x 2.49mm) | 1.398" L x 0.098" W (35.51mm x 2.49mm) | 1.398" L x 0.098" W (35.51mm x 2.49mm) |
| Height - Seated (Max) | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) |
