Please send RFQ , we will respond immediately.
| Part Number | 4416P-1-820 | 4416P-1-822 | 4416P-1-823 | 4416P-2-820 | 4416P-1-220 |
|---|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active | Active | Active |
| Circuit Type | Isolated | Isolated | Isolated | Bussed | Isolated |
| Resistance (Ohms) | 82 | 8.2k | 82k | 82 | 22 |
| Tolerance | ±2% | ±2% | ±2% | ±2% | ±1Ohm |
| Number of Resistors | 8 | 8 | 8 | 15 | 8 |
| Resistor Matching Ratio | - | - | - | - | - |
| Resistor-Ratio-Drift | 50ppm/°C | 50ppm/°C | 50ppm/°C | 50ppm/°C | 50ppm/°C |
| Number of Pins | 16 | 16 | 16 | 16 | 16 |
| Power Per Element | 160mW | 160mW | 160mW | 160mW | 160mW |
| Temperature Coefficient | ±100ppm/°C | ±100ppm/°C | ±100ppm/°C | ±100ppm/°C | ±250ppm/°C |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Applications | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | 16-SOIC (0.295", 7.50mm Width) | 16-SOIC (0.295", 7.50mm Width) | 16-SOIC (0.295", 7.50mm Width) | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOL | 16-SOL | 16-SOL | 16-SOL | 16-SOL |
| Size / Dimension | 0.410" L x 0.295" W (10.41mm x 7.50mm) | 0.410" L x 0.295" W (10.41mm x 7.50mm) | 0.410" L x 0.295" W (10.41mm x 7.50mm) | 0.410" L x 0.295" W (10.41mm x 7.50mm) | 0.410" L x 0.295" W (10.41mm x 7.50mm) |
| Height - Seated (Max) | 0.114" (2.90mm) | 0.114" (2.90mm) | 0.114" (2.90mm) | 0.114" (2.90mm) | 0.114" (2.90mm) |
