| Part Number | 3303C-1-104E | 3303C-1-105E | 3303C-1-204E | 3303C-1-504E | 3303D-1-104E | 3303C-1-101E | 3303C-1-102E | 3303C-1-103E |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Resistance | 100 kOhms | 1 MOhms | 200 kOhms | 500 kOhms | 100 kOhms | 100 Ohms | 1 kOhms | 10 kOhms |
| Power (Watts) | 0.15W | 0.15W | 0.15W | 0.15W | 0.15W | 0.15W | 0.15W | 0.15W |
| Tolerance | ±25% | ±25% | ±25% | ±25% | ±25% | ±25% | ±25% | ±25% |
| Temperature Coefficient | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C | ±250ppm/°C |
| Number of Turns | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Adjustment Type | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment | Top and Bottom Adjustment |
| Resistive Material | Cermet | Cermet | Cermet | Cermet | Cermet | Cermet | Cermet | Cermet |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Termination Style | J Lead | J Lead | J Lead | J Lead | J Lead | J Lead | J Lead | J Lead |
| Size / Dimension | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) | Rectangular - 0.148" x 0.118" Face (3.75mm x 3.00mm) |
