| Part Number | 15KPA051C-SD-Q | 15KPA058C-SD-Q | 15KPA054C-SD-Q |
|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - |
| Bidirectional Channels | 1 | 1 | 1 |
| Voltage - Reverse Standoff (Typ) | 51V | 58V | 54V |
| Voltage - Breakdown (Min) | 52.04V | 59.1V | 55.03V |
| Voltage - Clamping (Max) @ Ipp | 76.3V | 86.3V | 80.7V |
| Current - Peak Pulse (10/1000µs) | 182.1A | 161A | 172.2A |
| Power - Peak Pulse | 15000W (15kW) | 15000W (15kW) | 15000W (15kW) |
| Power Line Protection | No | No | No |
| Applications | Automotive | Automotive | Automotive |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | DO-218AB | DO-218AB | DO-218AB |
| Supplier Device Package | DO-218 | DO-218 | DO-218 |
