| Part Number | 1.5SMBJ20A | 1.5SMBJ30A | 1.5SMBJ24A | 1.5SMBJ22A | 1.5SMBJ26A | 1.5SMBJ60A | 1.5SMBJ28A | 1.5SMBJ40A | 1.5SMBJ20CA | 1.5SMBJ70A | 1.5SMB20A |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Type | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | - | 1 | 1 |
| Bidirectional Channels | - | - | - | - | - | - | - | - | 1 | - | - |
| Voltage - Reverse Standoff (Typ) | 20V | 30V | 24V | 22V | 26V | 60V | 28V | 40V | 20V | 70V | 17.1V |
| Voltage - Breakdown (Min) | 22.2V | 33.3V | 26.7V | 24.4V | 28.9V | 66.7V | 31.1V | 44.4V | 22.2V | 77.8V | 19V |
| Voltage - Clamping (Max) @ Ipp | 32.4V | 48.4V | 38.9V | 35.5V | 42.1V | 96.8V | 45.4V | 64.5V | 32.4V | 113V | 27.7V |
| Current - Peak Pulse (10/1000µs) | 46.3A | 31A | 38.6A | 42.3A | 35.7A | 15.5A | 33.1A | 23.3A | 46.3A | 13.3A | 54.9A |
| Power - Peak Pulse | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) |
| Power Line Protection | No | No | No | No | No | No | No | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | Telecom |
| Capacitance @ Frequency | - | - | - | - | - | - | - | - | - | - | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB | DO-214AA, SMB |
| Supplier Device Package | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | SMB (DO-214AA) | DO-214AA (SMBJ) |
