Please send RFQ , we will respond immediately.
| Part Number | THJA104K035RJN | THJA104M035RJN | THJA154K035RJN | THJA105K035RJN |
|---|---|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX |
| Product Status | Active | Active | Active | Active |
| Capacitance | 0.1 µF | 0.1 µF | 0.15 µF | 1 µF |
| Tolerance | ±10% | ±20% | ±10% | ±10% |
| Voltage - Rated | 35 V | 35 V | 35 V | 35 V |
| Type | Molded | Molded | Molded | Molded |
| ESR (Equivalent Series Resistance) | 24Ohm @ 100kHz | 24Ohm @ 100kHz | 21Ohm @ 100kHz | 7.5Ohm @ 100kHz |
| Operating Temperature | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C |
| Lifetime @ Temp. | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.126" L x 0.063" W (3.20mm x 1.60mm) |
| Height - Seated (Max) | 0.071" (1.80mm) | 0.071" (1.80mm) | 0.071" (1.80mm) | 0.063" (1.60mm) |
| Lead Spacing | - | - | - | - |
| Manufacturer Size Code | A | A | A | A |
| Ratings | AEC-Q200 | AEC-Q200 | AEC-Q200 | AEC-Q200 |
| Features | Automotive | Automotive | Automotive | Automotive |
| Failure Rate | - | - | - | - |
