Please send RFQ , we will respond immediately.
| Part Number | RP60800R0100JNBK | RP60870R0100JNBK | RP60300R0100JNBK |
|---|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX |
| Product Status | Obsolete | Obsolete | Obsolete |
| Resistance | 100 Ohms | 100 Ohms | 100 Ohms |
| Tolerance | ±5% | ±5% | ±5% |
| Power (Watts) | 100W | 150W | 20W |
| Composition | Thin Film | Thin Film | Thin Film |
| Temperature Coefficient | 150ppm/°C | 150ppm/°C | 150ppm/°C |
| Operating Temperature | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C |
| Features | - | - | - |
| Coating, Housing Type | Aluminum Oxide | Aluminum Oxide | Aluminum Oxide |
| Mounting Feature | Flanges | Flanges | Flanges |
| Size / Dimension | 0.800" L x 0.230" W (20.30mm x 5.84mm) | 0.870" L x 0.375" W (22.10mm x 9.53mm) | 0.300" L x 0.200" W (7.62mm x 5.08mm) |
| Height - Seated (Max) | 0.150" (3.81mm) | 0.150" (3.81mm) | 0.150" (3.81mm) |
| Lead Style | Tab | Tab | Tab |
| Package / Case | Axial | Axial | Axial |
| Failure Rate | - | - | - |
