Please send RFQ , we will respond immediately.
| Part Number | MR065A103JAA | MR065A123JAA | MR065A153JAA | MR061A103JAA | MR065A103FAA | MR065A103GAA |
|---|---|---|---|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX |
| Product Status | Active | Active | Active | Active | Active | Active |
| Capacitance | 10000 pF | 0.012 µF | 0.015 µF | 10000 pF | 10000 pF | 10000 pF |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±1% | ±2% |
| Voltage - Rated | 50V | 50V | 50V | 100V | 50V | 50V |
| Temperature Coefficient | C0G, NP0 | C0G, NP0 | C0G, NP0 | C0G, NP0 | C0G, NP0 | C0G, NP0 |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Features | - | - | - | - | - | - |
| Ratings | - | - | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial | Radial | Radial | Radial |
| Size / Dimension | 0.290" L x 0.090" W (7.36mm x 2.28mm) | 0.290" L x 0.090" W (7.36mm x 2.28mm) | 0.290" L x 0.090" W (7.36mm x 2.28mm) | 0.290" L x 0.090" W (7.36mm x 2.28mm) | 0.290" L x 0.090" W (7.36mm x 2.28mm) | 0.290" L x 0.090" W (7.36mm x 2.28mm) |
| Height - Seated (Max) | 0.290" (7.36mm) | 0.290" (7.36mm) | 0.290" (7.36mm) | 0.290" (7.36mm) | 0.290" (7.36mm) | 0.290" (7.36mm) |
| Thickness (Max) | - | - | - | - | - | - |
| Lead Spacing | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) |
| Lead Style | Straight | Straight | Straight | Straight | Straight | Straight |
