| Part Number | M39006/25-0055 | M39006/25-0058 | M39006/25-0050 | M39006/25-0052 |
|---|---|---|---|---|
| Manufacturer | KYOCERA AVX | EXXELIA | KYOCERA AVX | KYOCERA AVX |
| Product Status | Active | Active | Active | Active |
| Capacitance | 330 µF | 27 µF | 33 µF | 120 µF |
| Tolerance | ±20% | ±10% | ±10% | ±10% |
| Voltage - Rated | 50 V | 60 V | 50 V | 50 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | 1.53Ohm | 5.01Ohm | 4.95Ohm | 2.49Ohm |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.406" Dia x 1.062" L (10.31mm x 26.97mm) | 0.219" Dia x 0.453" L (5.56mm x 11.51mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) |
| Height - Seated (Max) | - | - | - | - |
| Lead Spacing | - | - | - | - |
| Manufacturer Size Code | T4 | T1 | T2 | T2 |
| Ratings | - | - | - | - |
| Features | High Reliability | High Reliability | High Reliability | High Reliability |
| Failure Rate | M (1%) | M (1%) | M (1%) | M (1%) |
