Please send RFQ , we will respond immediately.
| Part Number | M39006/22-0117 | M39006/22-0617 | M39006/22-0167 | M39006/22-0157 | M39006/22-0137 | M39006/22-0217 | M39006/22-0107 | M39006/22-0110 | M39006/22-0111 | M39006/22-0113 | M39006/22-0114 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | KYOCERA AVX | Vishay Sprague | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | EXXELIA | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Capacitance | 150 µF | 56 µF | 15 µF | 68 µF | 82 µF | 25 µF | 40 µF | 68 µF | 68 µF | 100 µF | 100 µF |
| Tolerance | ±10% | ±10% | ±20% | ±10% | ±10% | ±10% | ±20% | ±20% | ±10% | ±20% | ±10% |
| Voltage - Rated | 30 V | 75 V | 75 V | 60 V | 50 V | 125 V | 30 V | 30 V | 30 V | 30 V | 30 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | 2.03Ohm | - | 5.31Ohm | 2.54Ohm | 2.43Ohm | 3.18Ohm | 3.32Ohm | 2.54Ohm | 2.54Ohm | 2.26Ohm | 2.26Ohm |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - | - | - | - | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) | 0.406" Dia x 0.828" L (10.31mm x 21.03mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) | 0.406" Dia x 0.766" L (10.31mm x 19.46mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - | - | - | - |
| Lead Spacing | - | - | - | - | - | - | - | - | - | - | - |
| Manufacturer Size Code | T3 | T3 | T2 | T3 | T3 | T3 | T2 | T2 | T2 | T3 | T3 |
| Ratings | - | - | - | - | - | - | - | - | - | - | - |
| Features | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum |
| Failure Rate | M (1%) | R (0.01%) | M (1%) | M (1%) | M (1%) | M (1%) | M (1%) | M (1%) | M (1%) | M (1%) | M (1%) |
