KYOCERA AVX-FE52N6L0206KB - Film Capacitors Product Specifications and Latest Quotes

Related Product By Categories

$SQCAEM0R1BATME\500$

$04025J4R0ABSTR\500$

Capacitance:	20 µF
Tolerance:	±10%
Voltage Rating - AC:	-
Voltage Rating - DC:	1100V (1.1kV)
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	8.5 mOhms
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Through Hole
Package / Case:	Radial - 4 Leads
Size / Dimension:	2.264" L x 1.181" W (57.50mm x 30.00mm)
Height - Seated (Max):	1.772" (45.00mm)
Termination:	PC Pins
Lead Spacing:	2.067" (52.50mm)
Applications:	DC Link, DC Filtering
Ratings:	-
Features:	Low ESR
