| Part Number | AQ147M120JAJWE | AQ147M130JAJWE | AQ147M150JAJWE | AQ147M160JAJWE | AQ147M180JAJWE | AQ147M220JAJWE | AQ147M100JAJWE | AQ147M110JAJWE | AQ147M120FAJWE | AQ147M120JAJBE | AQ147M120JAJME |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX | KYOCERA AVX |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Capacitance | 12 pF | 13 pF | 15 pF | 16 pF | 18 pF | 22 pF | 10 pF | 11 pF | 12 pF | 12 pF | 12 pF |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±1% | ±5% | ±5% |
| Voltage - Rated | 500V | 500V | 500V | 500V | 500V | 500V | 500V | 500V | 500V | 500V | 500V |
| Temperature Coefficient | M | M | M | M | M | M | M | M | M | M | M |
| Operating Temperature | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C |
| Features | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss | High Q, Low Loss |
| Ratings | - | - | - | - | - | - | - | - | - | - | - |
| Applications | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency | RF, Microwave, High Frequency |
| Failure Rate | - | - | - | - | - | - | - | - | - | - | - |
| Mounting Type | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC |
| Package / Case | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) | 1111 (2828 Metric) |
| Size / Dimension | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) | 0.110" L x 0.110" W (2.79mm x 2.79mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - | - | - | - |
| Thickness (Max) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) | 0.102" (2.59mm) |
| Lead Spacing | - | - | - | - | - | - | - | - | - | - | - |
| Lead Style | - | - | - | - | - | - | - | - | - | - | - |
