Please send RFQ , we will respond immediately.
| Part Number | 5WF503MEGAA | 5WF503MXGAA |
|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX |
| Product Status | Obsolete | Obsolete |
| Capacitance | 0.05 µF | 0.05 µF |
| Tolerance | ±20% | ±20% |
| Voltage - Rated | 25V | 25V |
| Temperature Coefficient | Y5P (B) | Y5P (B) |
| Operating Temperature | -30°C ~ 85°C | -30°C ~ 85°C |
| Features | - | - |
| Ratings | - | - |
| Applications | General Purpose | General Purpose |
| Failure Rate | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial, Disc | Radial, Disc |
| Size / Dimension | 0.394" Dia (10.00mm) | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.197" (5.00mm) | 0.197" (5.00mm) |
| Thickness (Max) | - | - |
| Lead Spacing | 0.236" (6.00mm) | 0.236" (6.00mm) |
| Lead Style | Straight | Formed Leads - Kinked |
