| Part Number | 5AT220JBECA | 5AT270JBECA |
|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX |
| Product Status | Obsolete | Obsolete |
| Capacitance | 22 pF | 27 pF |
| Tolerance | ±5% | ±5% |
| Voltage - Rated | 3000V (3kV) | 3000V (3kV) |
| Temperature Coefficient | C0G, NP0 | C0G, NP0 |
| Operating Temperature | -30°C ~ 125°C | -30°C ~ 125°C |
| Features | - | - |
| Ratings | - | - |
| Applications | General Purpose | General Purpose |
| Failure Rate | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial, Disc | Radial, Disc |
| Size / Dimension | 0.315" Dia (8.00mm) | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.157" (4.00mm) | 0.157" (4.00mm) |
| Thickness (Max) | - | - |
| Lead Spacing | 0.295" (7.50mm) | 0.295" (7.50mm) |
| Lead Style | Straight | Straight |
