| Part Number | 046232112015800+ | 046232114015800+ |
|---|---|---|
| Manufacturer | KYOCERA AVX | KYOCERA AVX |
| Product Status | Active | Active |
| Flat Flex Type | FFC, FPC | FFC, FPC |
| Mounting Type | Surface Mount | Surface Mount |
| Connector/Contact Type | Contacts, Vertical - 1 Sided | Contacts, Vertical - 1 Sided |
| Number of Positions | 12 | 14 |
| Pitch | 0.039" (1.00mm) | 0.039" (1.00mm) |
| Termination | Solder | Solder |
| FFC, FCB Thickness | 0.30mm | 0.30mm |
| Height Above Board | 0.201" (5.10mm) | 0.201" (5.10mm) |
| Locking Feature | - | - |
| Cable End Type | Straight | Straight |
| Contact Material | Copper Alloy | Copper Alloy |
| Contact Finish | Tin Copper | Tin Copper |
| Housing Material | Plastic | Plastic |
| Actuator Material | - | - |
| Features | Low Insertion Force (LIF) | Low Insertion Force (LIF) |
| Voltage Rating | 50V | 50V |
| Operating Temperature | -20°C ~ 85°C | -20°C ~ 85°C |
| Material Flammability Rating | - | - |
